nanoIR2 uses pulses of a quantum cascade or an optical parametric oscillator laser for inducing a rapid thermal expansion which excite resonant oscillations of the AFM cantilever. The instrument is able to obtain AFM and IR maps simultaneously with a 20nm special resolution. Biological samples are normally mounted in typical CaF2 windows.
The Perkin Elmer Spectrum 2 is an ATR-FTIR spectrometer for the direct measurement of solid and liquid samples as well as smears dried onto glass slides. This range of samples is possible due to an internal standard that corrects for atmospheric moisture. Sleek and easy to use, it is ideal for the clinical setting. The instrument has a wavenumber resolution of 0.5 to 64 cm− 1.
Small, mid-infrared spectrometer designed to provide the capabilities of much larger, traditional FTIR spectrometers, but without the complexity. The attenuated total reflectance (ATR) system provides quick and easy measurement of liquids, powders, pastes and gels.
The Agilent Cary 670 FTIR air-bearing spectrometer in combination with an FTIR microscope system enables step-scan, TGA-IR, microscopy and chemical imaging. The scalable system is can be applied for polymers and materials, for pharmaceuticals, biotechnology and chemicals.
The Bruker ALPHA is a compact attenuated total reflection Fourier transform infrared (ATR-FTIR) spectrometer equipped with a diamond crystal and a RockSolid interferometer designed for at site analysis. It allows for measurements of samples directly in the solid or liquid state. The instrument has a wavenumber resolution beginning with 2 cm− 1 and a spectral range of 20,000 to 200 cm− 1.
Benchtop mid-IR macro spectroscopy with convenience of diamond ATR sampler.
Features a liquid nitrogen cooled detector for more sensitive measurements.
Heated diamond ATR top plate option available provides temperature control from ambient to 200 °C.
The Daylight Solutions Spero is a tuneable quantum cascade laser based infrared microscope to scan over a spectral range from 1800 to 900 cm -1. It is equipped with two infrared and one visible objective and allows for high performance spectral imaging of a sample.
For routine UV-Vis analysis.
The inVia Qontor is Renishaw's most advanced Raman microscope. LiveTrack™ focus tracking technology enables users to analyse samples with uneven, curved or rough surfaces. Available laser excitation wavelengths: 488 nm, 514 nm and 633nm.
Ntegra NT-MDT AFM-Raman prototype microscope with excitation at 532nm & 785nm. The Renishaw Raman section features a dual CCD camera including an ANDOR CCD as well as the standard issue Renishaw CCD. Its upright microscope is designed to enable opaque samples to be imaged by TERS.
The Renishaw RM2000 Raman microscope system compliments the above InVia systems with additional wavelengths ready for use. Available laser excitation wavelengths: 780 and 830 nm.
Enables a user to collect single spectra as well as hyperspectral images with full Raman spectrum at every image pixel. The system is suitable for a great variety of materials, with special focus on biological samples. Available laser excitation wavelengths: 532 and 785 nm.
